TessaBike1

Engine and TransmissionEdit

Engine type: 1 cylinders, 2-stroke, Single

Displacement: 124 cc (7.58 cubic inches)

Bore × stroke: 2.13 inch × 2.15 inch (square)

Cooling system: Water cooled

Throttle: Cable operated

Valves
Valve train: Reed valve, variable

Fuel and ignition
Sparks per cylinder: 1

Fuel supply system: Carburetor

Ignition type: Digital CDI

Funnel diameter: 1.54 inch

Compression: 12:1

Engine mounting: Transverse

Lubrication system: Oil pump

Gear box: Manual 6-speed

Clutch: Wet, multiple discs, hydraulic operated

Final drive: Chain

Starter: Kick-starter

DimensionsEdit

Wheel base: 58.3 inch

Ground clearance: 15.55 inch

Seat height: 39.1 inch

Weight
Dry weight: 200.6 lbs

Chassis and SuspensionEdit

Frame type: aluminium, Double cradle frame

Front
Suspension: Cartridge - upside-down

Suspension travel: 11.81 inch

Brake: Single Disk, Ø10.24 inch

Tire: 80 / 100 R21

Tire pressure: 0.07 PSI Rear
Suspension: mono shock, Swingarm

Suspension travel: 12.99 inch

Brake: Disk, Ø8.66 inch

Tire: 100 / 90 R19

Tire pressure: 0.07 PSI

OtherEdit

Fuel capacity: 1.98 gals
